Компоненты материнской платы

PCI_E1~3: Слоты расширения PCIe

PCI_E1

PCI_E2

PCI_E3

⚠

Внимание!

∙



MSI Gaming Series Graphics Card Bolster



∙



PCI_E1.

∙









JTBT1: Разъем для установки карты расширения

Thunderbolt



Thunderbolt.

2 16

1 TBT_Force_PWR 2 TBT_S0IX_Entry_REQ

3 TBT_CIO_Plug_Event# 4 TBT_S0IX_Entry_ACK

5 SLP_S3#_TBT 6 TBT_PSON_Override_N

7 SLP_S5#_TBT 8 No pin

9 Ground 10 SMBCLK_VSB

11 DG_PEWake 12 SMBDATA_VSB

13 TBT_RTD3_PWR_EN 14 Ground

15 TBT_Card_DET_R# 16 PD_IRQ#

MSI MPG Z590M User Manual
