Getting Started
1-3
Connectors
Back Panel
- 3 Component Video Out (RGB)
- 8 Audio RCA Out (for 8-channel audio support)
- 1 Digital Video / Audio Out (HDMI)
- 4 USB 2.0 Ports
- 1 IEEE 1394 Port
- 1 VGA Out (D-Sub)
- 1 LAN Jack (RJ45)
On-Board Pinheaders
- 2 USB 2.0 Pinheaders
- 1 CD-In Pinheader
- 1 TV-Out Pinheader
- 2 SPDIF-Out/In Pinheaders
- 1 VGA Pinheader
Slots
- 1 PCI slot
- 1 PCI Express x16 slot
- 1 PCI Express x1 slot
- Supports 3.3V / 5V PCI bus Interface
Form Factor
- Standard Micro-ATX (24.4 cm X 24.4 cm)
Mounting
- 8 mounting holes
