MSI MS-7798 (v2.x) User Manual

2-17
MS-7798
Chapter 2
ECO
Important
Once you clck the “ECO” button n the pre-set area, some tems n ECO menu wll be
󰘰xed and un-adjustable.
EuP 2013
Energy Usng Products Lot 6 2013 (EUP) reduces power consumpton when system s
o󰘯 or n standby mode.
Note: When enabled, the system wll not support RTC wake up event functons.
C1E Support
To enable ths tem to reduce the CPU power consumpton whle dle. Not all processors
support Enhanced Halt state (C1E).
Intel C-State
C-state s a power management state that detects when the system s dle and lowers
power consumpton accordngly.
Package C State lmt
Ths 󰘰eld allows you to select a C-state mode.
CPU Core Voltage/ CPU I/O Voltage/ GPU Voltage/ DRAM Voltage/ 3.3V/ 5V/ 12V
These tems show the voltages. Read only.
▶
▶
▶
▶
▶
