MSI MS-7865 User Manual

English
12
Motherboard Speci󰘰cations
Processor AMD Socket AM1 Processors■
Memory
Support
2x DDR3 memory slots supporting up to 32GB
Supports DDR3 1600/ 1333/ 1066 MHz
Single channel memory architecture
Supports non-ECC, un-bu󰘯ered memory
■
■
■
■
Expansion
Slots
1x PCIe 2.0 x16 slot, supports x4 speed
1x Mini-PCIe slot
■
■
Onboard
Graphics
1x VGA port, supporting a maximum resolution of 1920x1200
1x HDMI port, supporting a maximum resolution of 4096x2160
1x DVI-D port, supporting a maximum resolution of 1920x1200
■
■
■
Storage 2x SATA 6Gb/s ports■
USB 3.0 2x USB 3.0 ports on the back panel■
USB 2.0 6x USB 2.0 ports (2 ports on the back panel, 4 ports available
through the internal USB connectors)
■
Audio Realtek
®
ALC887 Codec■
LAN Realtek
®
RTL8111G Gigabit LAN controller■
Back Panel
Connectors
1x PS/2 keyboard port
1x PS/2 mouse port
1x VGA port
1x DVI-D port
1x HDMI port
2x USB 3.0 ports
2x USB 2.0 ports
1x LAN (RJ45) port
3x audio jacks
■
■
■
■
■
■
■
■
■
Internal
Connectors
1x 24-pin ATX main power connector
1x 4-pin ATX 12V power connector
2x SATA 6Gb/s connectors
2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
1x 3-pin CPU fan connector
1x 4-pin system fan connector
1x Front panel audio connector
1x Serial port connector
1x TPM connector
1x System panel connector
1x Chassis Intrusion connector
1x Clear CMOS jumper
■
■
■
■
■
■
■
■
■
■
■
■

MSI MS-7865 Specifications

General

Brand	MSI
Model	MS-7865
Category	Motherboard
Language	English
