IV. User Setup
1. Schematic Diagram of Keys
2. Description of Keys' Functions
Connect to the earphone
Signal transfer
Power supply
Note: The power must be greater than 10W
Type-C of the mobile phone as the signal source
Earphone jack
Mobile
power
supply
P button
Up button
Middle button
Down button
P button: [OSD status: Return / non-OSD status: Power]
Up button: [OSD status: Move up/ non-OSD status: Brightness adjusting
switch]
Middle button: [OSD status: Enter / non-OSD status: OSD switch]
Down button: [OSD status: Move down / non-OSD status: Volume adjusting
switch]
Note: Refer to the actual model for details.
(The picture is for reference only)
