Introductions
2-6 2-7
Right Side View
1. USB 3.1 Gen 1 Port (Type-C)
USB 3.1 Gen 1, the SuperSpeed USB 5Gbps, delivers the higher interface speeds for
connecting various devices, such as storage devices, hard drives, or video cameras,
and offers more advantages over high-speed data transferring.
The slim and sleek USB Type C connector features reversible plug orientation and
cable direction and supports 5V/1.5A portable charging power when AC power is
connected. However, the maximum portable charging power limitation may up to
5V/0.9A while only battery DC power is connected.
2. Thunderbolt (Type-C)
Thunderbolt™ 3 supports USB 3.1 Gen 2, PCIe, HDMI, DisplayPort connection; 5K
display monitor output; up to 40Gbps data rate; and 5V/3A portable charging power
when AC power is connected. However, the maximum portable charging power
limitation may up to 5V/0.9A while only battery DC power is connected.
3. Ventilator
The ventilator is designed to cool the system. DO NOT block the ventilator for air
circulation.
4. USB 3.1 Gen 2 Port
USB 3.1 Gen 2, the SuperSpeed USB 10Gbps, delivers the higher interface speeds
for connecting various devices, such as storage devices, hard drives, or video
cameras, and offers more advantages over high-speed data transferring.
5. HDMI Connector
HDMI (High-Definition Multimedia Interface) technology is the industry-leading
interface and de-facto standard connecting high-definition (HD) and ultra high-
definition (UHD) equipment.
