4
Specifications
CPU
Supports 12th Gen Intel® Core™ Processors, Pentium®
Gold and Celeron® Processors
Processor socket LGA1700
* Please go to www.msi.com to get the newest support status as new processors
are released.
Chipset Intel® B660 Chipset
Memory
4x DDR4 memory slots, support up to 128GB*
Supports 1R 2133/ 2666/ 3200 MHz (by JEDEC & POR)
Max overclocking frequency:
• 1DPC 1R Max speed up to 4800+ MHz
• 1DPC 2R Max speed up to 4000+ MHz
• 2DPC 1R Max speed up to 4000+ MHz
• 2DPC 2R Max speed up to 3600+ MHz
Supports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports Intel® Extreme Memory Profile (XMP)
* Please refer to www.msi.com for more information on compatible memory.
Expansion Slots
2x PCIe x16 slots
• PCI_E1 (From CPU)
• Support PCIe 4.0 x16
• PCI_E3 (From B660 chipset)
• Support PCIe 3.0 x4
3x PCIe x1 slots (From B660 chipset)
1x M.2 slot with E-key for PCIe WiFi module only (M2_3)
Multi-GPU Supports AMD CrossFire™ Technology
Onboard Graphics
1x VGA port, supports a maximum resolution of 2048x1536
60Hz, 1920x1200 60Hz
1x HDMI 2.1 with HDR port, supports a maximum
resolution of 4K 60Hz *
/
**
1x DisplayPort 1.4 port, supports a maximum resolution of
4K 60Hz *
/
**
* Available only on processors featuring integrated graphics.
** Graphics specifications may vary depending on the CPU installed.
Continued on next page
