OSD Menus

Extra

1st Level Menu 2nd Level Menu Description

Input Select Auto ∙ Selecting the video input source

HDMI™1

HDMI™2

DisplayPort

DDC/CI ON ∙ Turning on/off the DDC/CI support

OFF

HDMI™ CEC OFF ∙ HDMI™ CEC (Consumer Electronics

Control) supports Sony PlayStation®,

Nintendo® Switch™, Xbox Series X|S

consoles and various audio-visual devices

that are CEC-capable.

∙ If HDMI™ CEC is set to ON:

• The monitor will automatically power on

when the CEC device is turned on.

• The CEC device will enter power saving

mode when the monitor is turned off.

Reset YES ∙ Resetting and restoring settings to original

OSD defaults

Information ∙ Showing the information of the main image

source

Questions and Answers:

Need help?

Do you have a question about the MSI PRO MP341CQW and is the answer not in the manual?

MSI PRO MP341CQW Specifications

General

Panel type	VA
Color depth	10 bit
Pixel pitch	0.23175 x 0.23175 mm
Aspect ratio	21:9
Display diagonal	34 \
Anti-glare screen	Yes
Display technology	-
Vertical scan range	48 - 100 Hz
Screen curvature rating	1500R
Viewable size, vertical	333.72 mm
sRGB coverage (typical)	116.25 %
Contrast ratio (dynamic)	100000000:1
Contrast ratio (typical)	3000:1
Display number of colors	1.07 billion colors
Display diagonal (metric)	86.36 cm
Viewable size, horizontal	797.22 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	3440 x 1440
Headphone outputs	1
DisplayPort version	1.2a
VGA (D-Sub) ports quantity	0
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	- W
Package type	Box
Package depth	202 mm
Package width	998 mm
Package height	515 mm
Package weight	10300 g
Tilt angle range	-3.5 - 21.5 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Product color	White
Front bezel color	Black
Market positioning	Business
AMD FreeSync type	FreeSync
RMS rated power	4 W
