This connector allows you to connect the chassis intrusion switch cable.

Normal

(default)

Trigger the chassis

intrusion event



 Connect the  connector to the chassis intrusion switch/ sensor on the

chassis.

 Close the chassis cover.

 Go to .

 Set  to .

 Press  to save and exit and then press the  key to select .

 Once the chassis cover is opened again, a warning message will be displayed on

screen when the computer is turned on.



 Go to .

 Set  to Reset.

 Press to save and exit and then press the  key to select .



This connector is used to connect an optional Tuning Controller module.

2 6

1 No pin 2 NC

3 MCU_SMB_SCL_M 4 MCU_SMB_SDA_M

5 VCC5 6 Ground
