MSI Titan GT77 User Manual

2-10 2-11
Bottom Side View
1. Tweeter Speaker
The tweeter speaker is to reproduce high-pitched audio frequency.
2. Ventilator
The ventilator is designed to cool the system. DO NOT block the ventilator for air
circulation.
3. Battery Reset Hole (optional)
Whenever the system firmware (EC) is upgraded or the system hangs, please 1)
power off the notebook; 2) remove the AC power; 3) use a straightened paperclip and
insert it to this hole for 10 secs; 4) connect the AC power; 5) power on the notebook.
For models that do not support battery reset by Battery Reset Hole, please refer to
Power Key in Top-open View to execute battery reset.

MSI Titan GT77 Specifications

General

Processor	Intel Core i9-12900HX
Graphics	NVIDIA GeForce RTX 3080 Ti
Battery	99.9Whr
Operating System	Windows 11 Pro
Weight	3.3 kg
Wireless	Wi-Fi 6E, Bluetooth 5.2
Display	17.3-inch 4K UHD (3840 x 2160)
RAM	Up to 128GB DDR5
Storage	2TB NVMe SSD
Ports	HDMI
Keyboard	Per-key RGB mechanical keyboard
