Gettng Started
Expanson Slots
Ths manboard contans numerous ports for expanson cards, such as dscrete graphcs
or audo cards.
PCI_E1~E6: PCIe Expanson Slot
The PCIe slot supports the PCIe nterface expanson card.
PCIe 2.0 x16 Slot
PCIe 2.0 x1 Slot
PCIe 3.0 x16 Slot
Important
When addng or removng expanson cards, always turn o󰘯 the power supply and
unplug the power supply power cable from the power outlet. Read the expanson card’s
documentaton to check for any necessary addtonal hardware or software changes.
Graphcs Card Installaton Table
The followng table shows the graphcs cards nstallaton rules.
Symbol
●
: Install graphcs cards n to the PCIe slots.
Symbol
◎
: Connect the montor to the graphc card.
PCI_E1 PCI_E4 PCI_E6
1-WAY Graphcs Card
●◎
2-WAY Graphcs Cards
●◎ ●
● ●◎
3-WAY Graphcs Cards
● ● ●◎
Important
Only the graphcs card wth the symbol ◎ wll show POST message when you start up
your computer.
