MSI Z87-G43 GAMING User Manual

Chapter 1
1-21 Getting Started
Boot up the computer and install the drivers and software included in your video
card package. For more information, please refer to the manual that came with
your video card.
After all of the hardware and software has been properly installed, reboot the
system. After entering the operating system (OS), right click on the desktop and
choose the “Catalyst Control Center”.
3.
4.
The CrossFire™ setting must be enabled to allow CrossFire™ mode to operate.
The follow screen appears in the Catalyst Control Center. Depending on your
operating system, the screen may look di󰘯erent.
5.
Important
A CrossFire
TM
system has four possible display modes:
SuperTiling
Scissor Mode
Alternate Frame Rendering
Super Anti-aliasing.
For more details, please consult the graphics card manual.
•
•
•
•

MSI Z87-G43 GAMING Specifications

General

Chipset	Intel Z87
Form Factor	ATX
CPU Socket	LGA 1150
Maximum Memory	32GB
PCI Express x16 Slots	2
PCI Express 3.0 x16	1
PCI Express 2.0 x16	1
PCI Express x1	2
PCI Slots	3
SATA Ports	6 x SATA 6Gb/s
USB Ports	6 x USB 3.0, 8 x USB 2.0
Multi-GPU Support	AMD CrossFireX
Memory Slots	4
Memory Standard	DDR3 1066/1333/1600
Audio	Realtek ALC1150
LAN	Killer E2205 Gigabit LAN
RAID Support	RAID 0, 1, 5, 10
Power Connectors	24-pin ATX main power connector, 8-pin ATX 12V power connector
