12
SPA SET-UP
1
3
2
3. Connect the control box to the spa pool in right order. (There should be sealing ring at each connection point.)
4. Unscrew the valve cap and make sure that the center valve pin is in the “UP” position. If it is in the “DOWN”
position, press down on the valve pin and turn it counterclockwise until it pops up.
5. Attach the pressure gauge and the pump hose to the pump and secure it tightly. Connect the pump nozzle into
the valve receptacle on the spa body, and tighten it clockwise.
6. Start pumping air into the SPA tub by sliding the pump piston up and down, inflate the spa to 12 - 15PSI.
1. Spread out and connect the 9 pcs foam mat at a cleared area. Heat Preservation Mat prevents heat loss from
the bottom of the unit.
2. Put the pool body on the mat (note that the drain valve is in the appropriate area)
1
2
3
To Next Page
