Mustang Survival MD2017 INFLATABLE PFD User Manual

4
2) Put the Inflatable PFD on just like a jacket (Fig. 2) and fasten the
front buckle. Adjust the waist belt using the side buckle on the
belt and secure the belt’s loose end in the belt loop.
Warning: Do not wear Inflatable PFDs under clothing as
the inflation could be restricted or you could be injured.
Donning
Figure 2
INFLATING YOUR INFLATABLE PFD
It is recommended that the following procedures be followed to
inflate your Inflatable PFD:
1) Manual Inflation
Activate the inflation system by jerking firmly downward on the
pull-tab (Fig. 3). The Inflatable PFD should fully inflate within 5
seconds.
MD2015 MD2017
Manual Inflator Automatic Inflator
Figure 3
HT3160_MD2015_MD2017_28AUG2015.indd 4 28/08/2015 10:39:33 AM

Mustang Survival MD2017 INFLATABLE PFD Specifications

General

Brand	Mustang Survival
Model	MD2017 INFLATABLE PFD
Category	Safety Equipment
Language	English
