DISPLAY ASSEMBLY
PCB BOARD
1000 * PCB-N0A10C-DISP DISPLAY ASSEMBLY
BACKLIGHT
M502 2450-1146-0 EL BACKLIGHT
LCD
M501 2460-1340-1 LCD DISPLAY (522)
IR SENSOR
M113 4816-043T-3 IR SENSOR PIC-26043TM2
CONN ECTOR WIRES
M505A, M505B 7009-9630-0 CONN WIRE ASSY 14P 100MM
M509A 7010-1300-1 CN ASSY SHIELD 2P P2.5
KEYBOARD BOARD
PCB BOARD
2000 * PCB-N0A10C-KEY KEYBOARD ASSEMBLY
SWITCHES
M101-M110 5200-3538-0 SWITCH, TACT SKHHBY 7MM
CONNECTOR WIRE
M120C 7705-1120-2204 CONN ASSY 5P P2.5 L=120
RESISTORS
R301,R306,R307 4711-102A-2 RMF 1/8W 1K 1% AT
R302,R303 4711-622A-2 RMF 1/8W 6.2K 1% AT
R304,R305 4711-202A-2 RMF 1/8W 2K 1% AT
LED BOARD
PCB BOARD
6000 * PCB-N0A10C-LED LED ASSEMBLY
LED
D304 3700-3517-RG LED RED/GREEN (L-469HGW)
CONN WIRE
M301B 7703-1280-2004 CONN.ASSY 3P P2.5 L=280
LIVE
ASSEMBLY
PCB BOARD
3000 *AH PCB-N0A10C-LIVE LIVE ASSEMBLY
3000 *C PCB-N0A11C-LIVE LIVE ASSEMBLY
CAPACITOR
C800 8910-0049-0 CAP400V 4700P DE7150F472MVA1KC
ELECTRICAL PARTS LIST
Reference No. Part No. Description

NAD C 521i Specifications

General

Brand	NAD
Model	C 521i
Category	CD Player
Language	English
