ENGLISH
24
DSP Options: 5ms
Tone Controls: Tone Defeat/On
Front Panel Display Setup: Set “Other Sources Front View” to “Source
(Simple)”
5 With the above settings, scroll to “A/V Presets” from the SETUP MENU
page. Use [S] to access “A/V Presets” menu.
6 At “A/V Presets” page, set “Preset: 2” to the following conditions - use
[D/F] to select “Yes” or “No” and press [ENTER] to conrm selection and
move to the next setting.
While at “Save Current Setup to Preset” menu line, use [S] to save the
settings above to “Preset 2”. When you recall “Preset 2” using the remote
control (for HTR 8, “A/V PSET” + “2”), the above preset values allocated at
“Preset 2” (preset settings as shown in the OSD captures at Step 4) will
be recalled and eected at the current source.
Note that “Speaker Setup” is set to “No”. At this condition, there will
be no “Speaker Setup” values that will be eected at “Preset 2”. The
“Speaker Setup” settings that will be applied at “Preset 2” will be the last
or current “Speaker Setup” settings which in this sample are the same
“Speaker Setup” settings shown above in Step 1.
7 You can setup up to 5 A/V Presets. These same A/V Presets can also be
associated/defaulted to each Source in the “Source Setup” window as
below.
In the above example, “Preset 1” settings are allocated for Source 1.
Whenever Source 1 is accessed, the “Preset 1” settings will be applied
to Source 1. You can still manually override the assigned A/V Preset
allocation in a specic Source with another Preset setting/number by
way of pressing the appropriate remote control buttons.
RECALLING PRESETS
You may recall an A/V Preset number at any time using the HTR 8 remote
control. Press the HTR 8’s A/V PSET key and then the numeric key 1-5
corresponding to the desired A/V Preset number. The newly recalled A/V
Preset will then manifest or replace the previous A/V Preset (if any).
OPERATION
CONFIGURING T 778 SETUP MENU VIA ONSCREEEN DISPLAY
