© National Instruments Corporation 3-1 PCI/PXI-6703/6704 User Manual
3
Signal Connections
This chapter provides connection instructions for the signals on your
6703/6704 device I/O connector.
Warning
Connections that exceed any of the maximum ratings of input or output signals
on the 6703/6704 device can damage the device and the computer. Maximum input ratings
for each signal are given in this chapter under the discussion of that signal. National
Instruments is
NOT
liable for any damages resulting from any incorrect signal connections.
I/O Connector Pin Assignments
Figure 3-1 shows the I/O connector pin assignments for the
6703/6704 devices.

National Instruments PCI-6703 Specifications

General

Type	Analog Output
Device Type	PCI Card
Number of Channels	8
Resolution	16 bits
Maximum Update Rate	1 MS/s
Output Range	±10 V
Interface	PCI
Connector Type	68-pin VHDCI
Storage Temperature Range	-20 °C to 70 °C
Operating System	Windows, Linux
Relative Humidity Range	10% to 90% noncondensing
