National Instruments sbRIO-9609 User Manual

9-30 VDC
Input
Power
Selection and
Protection
On-board
Power
Supplies
Configurable per Module
NI-DAQmx
Technology
sbRIO-9609
Intel Atom E3845
Quad-Core
1.91 GHz Processor
High-Speed CAN
Xilinx Artix-7 200T
Real-Time
Clock
Battery
Holder
Power
Connector
RMC Connector
(240-pin 60x4 Searay)
Optional System
Power 9-30 VDC
2x C Series
Module Interface
Temperature
Sensors
Watchdog
4 GB
eMMC Disk
2 GB
DDR3L
CAN Port
CAN
Controller
5 V
3.3 V
SATA 2.0
PCIe x1 Gen 2
USB 2.0
VBAT
2.5 V/3.3 V
Power Selector
2.5 V/3.3 V
Power Selector
FPGA_VIO [0-47]
Digital I/O [0-47], SE/LVDS
Digital I/O [48-95], SE/LVDS
FPGA_VIO [48-95]
LabVIEW FPGA API Data Path
Processor Data Path
NI-DAQmx API Data Path
Power Path
External Connector/Port
RJ-45 TSN Gigabit
Ethernet Port
PHY
RJ-45 TSN Gigabit
Ethernet Port
PHY
USB 2.0 Device
Type-C Connector
UARTRS-232
RS-232
Console Out
XCVR
USB 3.1 Host
Type-C Connector
with DisplayPort
sbRIO-9609 Block Diagram
1
3
5
7
9
2
4
6
8
10
NC
V– (GND)
Shield
CAN1_H
NC
CAN1_L
NC
V– (GND)
NC
Shield
CAN Pinout
1
3
5
7
9
2
4
6
8
10
DCD
TXD
GND
RTS
RI
RXD
DTR
DSR
CTS
Shield
RS-232 (ASRL1) Pinout
1 32 4 5 6
7
1
2
3
4
1. Power LED
2. Status LED
3. User1 LED
4. User FPGA1 LED
1. Power terminal 5. RS-232 serial port with Console Out
2. CAN port 6. RJ-45 Gigabit Ethernet ports
3. USB Type-C 2.0 device port 7. RMC connector
4. USB Type-C 3.1 host port
sbRIO-9609 LEDs
sbRIO-9609 Parts Locator Diagram

National Instruments sbRIO-9609 Specifications

General

Brand	National Instruments
Model	sbRIO-9609
Category	Control Unit
Language	English
