NEC MULTISYNC E201W User Manual

English
English-11
AUTO BRIGHTNESS
OFF: No function.
(AUTO BRIGHTNESS) 1: Automatically adjusts the brightness to the optimal setting by detecting the brightness
level of the environment*
1
.
(AUTO BRIGHTNESS) 2: Automatically adjusts the brightness to the optimal brightness setting based on the white
display area.
The environmental brightness sensor (Ambibright sensor) has no function.
(AUTO BRIGHTNESS) 3: Automatically adjusts the brightness to the optimal setting based on the white display area
and by using the Ambibright sensor to detect the brightness level of the environment.
*1: Please refer to Page 17 for full “Auto Brightness” information.
NOTE: This function is disabled when DV mode is set for Dynamic.
DV MODE
Dynamic Visual Mode allows you to select setting for Movie, Photo, Dynamic and etc.
STANDARD: Standard setting.
TEXT: Setting that makes letters and lines crisp; best suited for basic word processing and spreadsheets.
MOVIE: Setting that boosts dark tones; best suited for movies.
GAMING: Setting that boosts whole tones; best suited for games that use vivid, colorful images.
PHOTO: Setting that optimizes contrast; best suited for still images.
DYNAMIC: Setting that adjusts the brightness by detecting the screen’s black areas and optimizes it.
Auto Adjust (Analog input only)
Automatically adjusts the Image Position, Horizontal Size and Fine settings.
Image Controls (Analog input only)
LEFT / RIGHT
Controls Horizontal Image Position within the display area of the LCD.
DOWN / UP
Controls Vertical Image Position within the display area of the LCD.
H.SIZE
Adjusts the horizontal size by increasing or decreasing this setting.
FINE
Improves focus, clarity and image stability by increasing or decreasing this setting.
INPUT RESOLUTION (Analog Input Only)
Selects resolution’s priority of input signal to one of the following pair: 1360 x 768 or 1280 x 768 or 1024 x 768
(vertical resolution 768).
Colour Control System
Colour Control System: Six colour presets select the desired colour setting (sRGB and NATIVE colour presets are
standard and cannot be changed).
1, 2, 3, 5: Increases or decreases Red, Green or Blue colour depending upon which is selected. The change in
colour will appear on screen and the direction (increase or decrease) will be shown by the bars.
NATIVE: Original colour presented by the LCD panel that is unadjustable.
sRGB: sRGB mode dramatically improves the colour fidelity in the desktop environment by a single standard RGB
colour space. With this colour supported environment, the operator could easily and confidently communicate colour
without further colour management overhead in the most common situations.
NOTE: When MOVIE, GAMING, or PHOTO is selected as the DV MODE, NATIVE is selected automatically as the
six colour preset and cannot be changed.

NEC MULTISYNC E201W Specifications

General

3D	No
Panel type	TN
Pixel pitch	0.267 x 0.267 mm
Aspect ratio	16:9
Screen shape	Flat
Backlight type	W-LED
Display surface	-
Display diagonal	20 \
Display resolution	1600 x 900 pixels
Display technology	LED
Contrast ratio (dynamic)	25000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Digital vertical frequency	56 - 75 Hz
Digital horizontal frequency	31.5 - 82.3 kHz
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1360 x 768 (WXGA), 1400 x 1050 (SXGA+), 1440 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
USB Type-A downstream ports quantity	0
AC input voltage	100 - 240 V
Power consumption (max)	25 W
Annual energy consumption	26 kWh
Power consumption (standby)	- W
Power consumption (typical)	18 W
Power consumption (PowerSave)	0.42 W
Certification	CCC; CE; Energy Star 5.0; ErP; FCC Class B; GEEA/Energy Label; ISO 9241-307 (pixel failure class I); MPR II/ MPR III; PCT/Gost; TCO 5.0; TÜV Ergonomics; TÜV GS; UL/C-UL, CSA
Product color	Black
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Power consumption (economy mode)	12 W
Pivot angle	0 - 90 °
Tilt angle range	-5 - 20 °
Height adjustment	110 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Cables included	DVI, VGA
Sustainability certificates	EPEAT Gold, ENERGY STAR

Weight and Dimensions

Bezel width (top)	16 mm
Bezel width (side)	18.5 mm
Depth (with stand)	213.9 mm
Width (with stand)	447 mm
Height (with stand)	359.3 mm
Weight (with stand)	5400 g
Depth (without stand)	55 mm
Width (without stand)	477 mm
Height (without stand)	285.6 mm
Weight (without stand)	- g
