Your new NEC LCD monitor box* should contain the following:
Setup Manual Power Cord*
1
Video Signal Cable
Base Stand
LCD monitor
(Base Stand not connected)
Setup
Manual
DVI-D to DVI-D
cable
Audio Cable*
2
• LCD monitor with tilt base
• Power Cord*
1
• Video Signal Cable (DVI-D to DVI-D cable)
• Video Signal Cable (15-pin mini D-SUB male to 15-pin mini D-SUB male)
• Setup Manual
• Base Stand
• Audio cable*
2
* Remember to save your original box and packing material to transport or ship the monitor.
*
1
Type of power cord included will depend on the where the LCD monitor is to be shipped.
*
2
E233WM only.
The model name is on the label.
Rating label on the
back of the display.
Quick Start
To attach the Base to the LCD stand:
1. Place monitor face down on a non-abrasive surface (Figure 1).
NOTE: Handle with care when monitor facing down, for avoiding damage to the front control keys.
2. Please pivot base 90 degrees as shown in Figure 1.
NOTE: Handle with care when pulling the stand.
3. Attach the base stand to LCD monitor and properly lock screw of base stand bottom (Figure 2).
NOTE: Reverse this procedure if you need to re-pack the monitor.
Figure 1 Figure 2
Screw
To Next Page
