Specifications
Monitor Specifications MultiSync EA245WMi-2 Notes
LCD Module Diagonal:
Viewable Image Size:
Native Resolution (Pixel Count):
61.13 cm/24 inches
61.13 cm/24 inches
1920 x 1200
Active matrix; thin film transistor (TFT) liquid crystal
display (LCD); 0.270 mm dot pitch; 300 cd/m
2
white
luminance; 1000:1 contrast ratio (typical), (5000:1
Contrast ratio, Dynamic).
Input Signal
DisplayPort: DisplayPort Connector: Digital RGB DisplayPort V1.2 (HDCP 1.3)
DVI: DVI-D 24pin: Digital RGB DVI (HDCP 1.4)
VGA: 15pin Mini D-sub: Analog RGB
Sync
0.7 Vp-p/75 ohm
Separate sync.TTL level Positive/Negative
Composite sync.TTL level Positive/Negative
Sync on Green
(Video 0.7 Vp-p and Sync Negative 0.3 Vp-p)
HDMI: HDMI Connector: Digital YUV
Digital RGB
HDMI (HDCP 1.4)
Output Signal
DisplayPort: DisplayPort Connector: Digital RGB DisplayPort V1.2 (HDCP 1.3)
Display Colors 16,777,216
Synchronization Range Horizontal:
Vertical:
31.5 kHz to 95.0 kHz
56 Hz to 75 Hz
Automatically
Automatically
Viewing Angle Left/Right:
Up/Down:
±89°(CR>10)
±89°(CR>10)
Image Formation Time 6 ms (Gray to gray Typ.)
Resolutions Supported 720 x 400*
1
: VGA text Some systems may not support all modes listed.
640 x 480*
1
@ 60 Hz to 75 Hz
800 x 600*
1
@ 56 Hz to 75 Hz
832 x 624*
1
@ 75 Hz
1024 x 768*
1
@ 60 Hz to 75 Hz
1152 x 870*
1
@ 75 Hz
1280 x 1024*
1
@ 60 Hz to 75 Hz
1400 x 1050*
1
@ 60 Hz to 75 Hz
1440 x 900*
1
@ 60 Hz
1600 x 1200*
1
@ 60 Hz
1680 x 1050*
1
@ 60 Hz
1920 x 1080*
1
@ 60 Hz
1920 x 1200 @ 60 Hz........................................... NEC DISPLAY SOLUTIONS cites recommended.
Active Display Area Landscape: Horiz.:
Vert.:
Portrait: Horiz.:
Vert.:
518.4 mm/20.4 inches
324.0 mm/12.8 inches
324.0 mm/12.8 inches
518.4 mm/20.4 inches
USB Hub I/F:
Port:
Load Current:
USB Specification Revision 3.1 Gen 1
Upstream 1
USB 3.1 Gen 1 Downstream 3
Maximum 0.9 A per port for USB 3.1 Gen 1
USB 3.1 Gen 1 Upstream port applicable to USB
monitor control.
AUDIO
AUDIO Input: STEREO Mini Jack:
DisplayPort Connector:
HDMI Connector:
Analog Audio
Digital Audio
Digital Audio
Stereo L/R 500mV rms 20 Kohm
PCM 2ch 32, 44.1, 48 kHz (16/20/24bit)
PCM 2ch 32, 44.1, 48 kHz (16/20/24bit)
Headphone Output: STEREO Mini Jack: Headphone Impedance 32 Ohm
Speakers Practical Audio Output: 1.0 W + 1.0 W
ControlSync IN:
(available up to 24 sub monitors) OUT:
Stereo Micro jack 2.5 φ
Stereo Micro jack 2.5 φ
Power Supply AC 100-240 V, 50/60 Hz
Current Rating 0.90 - 0.50 A
Dimensions Landscape:
Portrait:
Height Adjustment:
531.5 mm (W) x 365.4 - 515.4 mm (H) x 250.0 mm (D)
20.9 inches (W) x 14.4 - 20.3 inches (H) x 9.8 inches (D)
347.8 mm (W) x 549.5 - 613.2 mm (H) x 250.0 mm (D)
13.7 inches (W) x 21.6 - 24.1 inches (H) x 9.8 inches (D)
150 mm/5.9 inches (Landscape orientation)
63.7 mm/2.5 inches (Portrait orientation)
Weight 6.7 kg (14.8 lbs)/Without stand: 4.2 kg (9.3 lbs)
Environmental Considerations
Operating Temperature:
Humidity:
Altitude:
Storage Temperature:
Humidity:
Altitude:
5°Cto35°C/41°Fto95°F
20% to 80%
0 to 16,404 Feet/0 to 5,000 m
-10°Cto60°C/14°Fto140°F
10% to 85%
0 to 40,000 Feet/0 to 12,192 m
*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is normal and
necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each dot on the screen is actually
one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
NOTE: Technical specifications are subject to change without notice.
