Top panel LEDs and buttons
The status LEDs and two buttons are located on the top panel of the router.
Figure 2. Top view
Table 1. LED descriptions
DescriptionLED and Button
•
Solid white. The router is ready.
•
Blinking white. The router is not ready, firmware is upgrading, or the Reset
button was pressed.
•
Off. Power is not supplied to the router.
Power LED
•
Solid white. The Internet connection is ready.
•
Blinking white. The port is sending or receiving traffic.
•
Off. No Ethernet cable is connected between the router and the modem.
Internet LED
User Manual10Hardware Setup
Nighthawk AX6 6-Stream AX5400 WiFi Router
