INTRODUCTION
Basicinstructions-Loaderarmlockandcabtiltprocedure-
verticalliftmachines
C332
C338TIER3[NJM453496-]
L318
L320
L323TIER3[NJM453496-]
L325TIER3[NJM453496-]
L330TIER3[NJM453496-]
DANGER
Crushinghazard!
Donotenterorexittheoperator'scompartmentwhiletheloaderarmsareraisedorunsupported.Rest
theloaderarmsonthegroundorverifythatloaderarmisbeingsupportedbytheloaderarmstrutor
loaderarmlockpinbeforeenteringorexitingtheoperator'scompartment.
Failuretocomplywillresultindeathorseriousinjury.
D0168A
Raiseandlocktheloaderarmformachineservice
1.Sitintheoperator'sseat,fastentheseatbelt,pullthe
restraintbar(ifequipped)down,andstarttheengine.
2.Presstheoperatebuttontoenablethehydraulics.
3.Removethebucketorattachmentfromthemounting
plate.See“Mechanicalattachmentmountingsys-
tems”(Couplingbrackets-Lock/Unlock(82.100))
or“Hydraulicattachmentmountingsystems”(Hy-
draulicattachmentmountingsystems(35.734))for
assistance.
4.Parkthemachineonalevelsurface.
200929241
5.Fullyraisetheloaderarm.
RAPH14SSL0351BA2
5151785810/11/2020
32
