INTRODUCTION
Safetyrules
HeaderSafetyStop
WARNING
Avoidinjury!Alwaysdothefollowingbeforelubricating,maintaining,orservicingthemachine.
1.Disengagealldrives.
2.Engageparkingbrake.
3.Lowerallattachmentstotheground,orraiseandengageallsafetylocks.
4.Shutoffengine.
5.Removekeyfromkeyswitch.
6.Switchoffbatterykey,ifinstalled.
7.Waitforallmachinemovementtostop.
Failuretocomplycouldresultindeathorseriousinjury.
W0047A
Theleft-handcylinderofthefeederisttedwithaheader
safetystop(1)whichmustbeloweredontothecylinder
rodtopreventaccidentalloweringoftheheader.
830609251
Toengageordisengagetheheadersafetystopitisnec-
essarytoliftthefeedertoitsmaximumheight.
Todothis,proceedasfollows:
1.Selecteldmodeusingtheeld/roadmodeselector
switch(1).
2.Movethefeederupbypressingonthetopofheader
heightrockerswitch(2)ontheMFHuntiltheheader
stopsnearitsmaximumheight.
3.Releasetheswitchandpressagainforaminimum
of1.5s.Theheaderwillnowmovequicklyuntilits
maximumheight.
4.Placetheheadersafetystopoverthecylinderrod.
NOTICE:Headerswithadjustablereelheightcancome
veryclosetothecabwindshieldwhentheheaderis
raised.Becautiouswhenliftingtheheadertoit'smaxi-
mumheight.
730745042
4766794324/04/2014
16
