20
When using the unit in vehicle, you can use the supplied mount accessories (mount
bracket, mount cradle and dashboard mount disk) to mount the unit in the vehicle. Take
the following steps to operate:
1. See Fig. 1 to slide the mount cradle onto the end of the mount bracket.
2. See Fig. 2. Set the bottom edge of the unit onto the mount cradle. Then push the
tap at the top of the mount cradle in arrow 1 direction to mount the unit to the mount
cradle. To remove the unit, push the tap at the top of the mount cradle in arrow 1
opposite direction.
3. Lift the suction cup lever and then press the suction cup to the windshield. Then
press down the suction cup lever in arrow 2 direction to fix the bracket to the
windshield. At the end, rotate the knob to adjust the unit to proper position.
If you want to mount the unit to the dashboard, you can use the adhesive disk:
1) Choose a clean, dry spot on your dashboard.
2) Peel off protection liner from the back of the disk.
3) Attach the disk to your dashboard.
4) Mount the bracket to the adhesive disk.
Use of the Mount
Accessories
