52
A (Auto) Mode
Shooting Features
C Features That Cannot Be Used Simultaneously
These features may not be used in combination with certain features (A63).
White balance
Adjust colors in the image closer to the colors as they appear
to the eye. Although Auto (default setting) can be used
under most types of lighting, you can apply the white
balance setting suited to the sky conditions or light source to
achieve better results if default setting results are
unsatisfactory.
When the white balance setting is other than Auto or
Flash, set the flash mode (A54) to W (off).
E34
Continuous
Select the mode used for taking a series of pictures from
Single, Continuous H, Continuous L, BSS (A43) and
Multi-shot 16. The default setting is Single (i.e., only one
picture is captured at a time).
When set to Continuous H, up to three pictures are shot at
a rate of about 7.1 frames per second while the shutter-
release button is pressed all the way (when image mode is
set to Q 4608×3456).
E36
ISO sensitivity
Higher ISO sensitivity allows you to take pictures of darker
subjects. Additionally, even with subjects of similar
brightness, pictures can be taken with faster shutter speeds,
and blurring caused by camera shake and subject
movement can be reduced. When set to Auto (default
setting), the camera sets the ISO sensitivity automatically.
If ISO sensitivity has increased automatically when Auto is
selected, E (A28) is displayed on the shooting screen.
E37
AF area mode
Allow you to determine how the camera selects the focus
area for autofocus to Face priority (default setting), Auto,
Manual, Center or Subject tracking mode.
E38
Autofocus mode
Single AF (default setting) to adjust the focus only when the
shutter-release button is pressed halfway or Full-time AF to
adjust the focus even when the shutter-release button is not
pressed halfway can be selected. You may hear the sound of
the camera focusing.
E41
Option Description A

Table of Contents

Other manuals for Nikon COOLPIX AW100

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Nikon COOLPIX AW100 and is the answer not in the manual?

Nikon COOLPIX AW100 Specifications

General IconGeneral
Megapixel16 MP
Camera typeCompact camera
Sensor typeCMOS
Image stabilizerYes
Total megapixels16.79 MP
Image sensor size1/2.3 \
Image formats supportedJPEG XR
Maximum image resolution4608 x 3456 pixels
Still image resolution(s)-
Optical zoom5 x
Focal length range5 - 25 mm
Lens structure (elements/groups)12/10
Maximum focal length (35mm film equiv)140 mm
Minimum focal length (35mm film equiv)28 mm
FocusTTL
Focus adjustmentAuto/Manual
Auto focusing (AF) modesCentre weighted Auto Focus, Contrast Detection Auto Focus, Tracking Auto Focus
ISO sensitivity125, 400, 3200
Light exposure modesAperture priority AE, Auto, Shutter priority AE
ISO sensitivity (max)3200
ISO sensitivity (min)125
Light exposure controlProgram AE
Light exposure correction± 2EV (1/3EV step)
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/1500 s
Slowest camera shutter speed4 s
Flash range (tele)0.5 - 2.2 m
Flash range (wide)0.3 - 3.5 m
Power source typeBattery
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate30 fps
Video formats supportedH.264, MPEG4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Audio systemstereo
Audio formats supportedAAC, WAV
Memory slots1
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display resolution (numeric)460000 pixels
USB version2.0
HDMI connector typeMini
Scene modesBacklight, Beach, Close-up (macro), Cuisine, Dawn, Dusk, Fireworks, Museum, Night landscape, Night portrait, Panorama, Party (indoor), Pet, Portrait, Snow, Sports, Sunset, Underwater
Image editingCrop
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Manual
Self-timer delay2, 10 s
Languages supportARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Camera file systemDCF, DPOF, Exif 2.3
Battery life (CIPA standard)250 shots
Product colorBlue
Operating temperature (T-T)-10 - 40 °C
Weight and Dimensions IconWeight and Dimensions
Depth22.8 mm
Width110.1 mm
Height64.9 mm
Weight178 g
