127Recording and Viewing Movies
4 End recording.
Press the movie-record button again to end recording.
Recording will end
automatically when the maximum length is reached, the memory card is full,
another mode is selected, or the monitor is closed (closing the monitor does
not end recording on televisions or other external displays).
A Taking Photographs During Movie Recording
To end movie recording, take a photograph, and exit to live view, press the shutter-release
button all the way down and hold it in this position until the shutter is released.
A Maximum Length
The maximum length for individual movie files is 4 GB (for maximum recording times, see
page 128); note that depending on memory card write speed, shooting may end before this
length is reached (0 238).
D Recording Movies
Flicker, banding, or distortion may be visible in the monitor and in the final movie under
fluorescent, mercury vapor, or sodium lamps or if the camera is panned horizontally or an
object moves at high speed through frame (flicker and banding can be reduced using
Flicker reduction; 0 200).
Bright light sources may leave after-images when the camera is
panned.
Jagged edges, color fringing, moiré, and bright spots may also appear.
Bright
bands may appear in some areas of the frame if the subject is briefly illuminated by a flash or
other bright, momentary light source.
When recording movies, avoid pointing the camera at
the sun or other strong light sources.
Failure to observe this precaution could result in
damage to the cameras internal circuitry.
The camera can record both video and sound; do not cover the microphone during
recording.
Note that the built-in microphone may record lens noise during autofocus and
vibration reduction.
Flash lighting can not be used during movie recording.
Live view may end automatically to prevent damage to the cameras internal circuits; exit live
view when the camera is not in use.
Note that the temperature of the cameras internal
circuits may rise and noise (bright spots, randomly-spaced bright pixels, or fog) may be
displayed in the following instances (the camera may also become noticeably warm, but this
does not indicate a malfunction):
The ambient temperature is high
The camera has been used for extended periods in live view or to record movies
The camera has been used in continuous release mode for extended periods
If live view does not start when you attempt to start live view or movie recording, wait for the
internal circuits to cool and then try again.
Matrix metering is used regardless of the metering method selected.
Shutter speed and ISO
sensitivity are adjusted automatically unless On is selected for Manual movie settings
(0 129) and the camera is in mode M.

Table of Contents

Other manuals for Nikon D5300

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Nikon D5300 and is the answer not in the manual?

Nikon D5300 Specifications

General IconGeneral
Megapixel24.2 MP
Camera typeSLR Camera Body
Sensor typeCMOS
Sensor formatAdvanced Photo System type-C (APS-C)
Image stabilizerNo
Total megapixels24.78 MP
Image sensor size- \
Image formats supportedJPG, RAW
Supported aspect ratios3:2
Maximum image resolution6000 x 4000 pixels
Image sensor size (W x H)23.5 x 15.6 mm
Still image resolution(s)6000 x 4000, \\r 4496 x 3000, \\r 2992 x 2000
Optical zoom- x
Mounting typeBayonet
Focal length range- mm
Lens mount interfaceNikon F
Minimum aperture number-
FocusTTL
Focus adjustmentAuto/Manual
Auto Focus (AF) lockYes
Auto Focus (AF) points39
Auto focusing (AF) modesContinuous Auto Focus, Contrast Detection Auto Focus, Multi Point Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Auto Focus (AF) points selectionAuto, Manual
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity100, 12800, 25600, Auto
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)25600
ISO sensitivity (min)100
Light exposure correction± 5EV (1/3EV step)
Camera shutter typeElectronic
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed30 s
Flash modesAuto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash sync-speed1/200 s
Shoe mounting point typeHot shoe
Flash exposure correction-3EV - +1EV (1/3 EV step)
Power source typeBattery
Video resolutions640 x 424, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate60 fps
Video formats supportedH.264, MOV, MPEG4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Memory slots1
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3.2 \
Display resolution720 x 480 pixels
Display resolution (numeric)1036800 pixels
Magnification0.82 x
Viewfinder typeOptical
USB version2.0
HDMI connector typeMini
Product colorSilver
Scene modesPortrait, Landscape (scenery)
Photo effectsBlack&White, Neutral, Vivid
White balanceAuto, Cloudy, Flash, Fluorescent, Incandescent, Manual, Shade, Sunny
Playback modesRotation, Slideshow, Zoom
Shooting modesAperture priority, Auto, Lens priority, Manual, Movie, Program, Scene, Shutter priority
Camera playbackHighlights, Movie, Single image, Slide show
Image processorEXPEED 4
Self-timer delay2, 5, 10, 20 s
Camera file systemDCF 2.0, DPOF 1.1, Exif 2.3, RAW
Diopter adjustment (D-D)-1.7 - 1
On Screen Display (OSD) languagesARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Battery typeEN-EL14a
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)0 - 85 %
Cables includedUSB
Bundled softwareViewNX 2
Wi-Fi standards802.11b, 802.11g
Weight and Dimensions IconWeight and Dimensions
Depth76 mm
Width125 mm
Height98 mm
Weight480 g
Weight (including battery)530 g
