Other Accessories
At the time of writing, the following accessories were available for the D5300.
Power
sources
• Rechargeable Li-ion Battery EN-EL14a (0 9): Additional EN-EL14a batteries are
available from local retailers and Nikon-authorized service representatives.
EN-EL14 batteries can also be used.
• Battery Charger MH-24 (0 9): Recharge EN-EL14a and EN-EL14 batteries.
• Power Connector EP-5A, AC Adapter EH-5b: These accessories can be used to power
the camera for extended periods (EH-5a and EH-5 AC adapters can also be
used). A power connector EP-5A is required to connect the camera to the
EH-5b, EH-5a, or EH-5.
Filters
• Filters intended for special-effects photography may interfere with autofocus
or the electronic rangefinder.
• The D5300 can not be used with linear polarizing filters. Use C-PL or C-PL II
circular polarizing filters instead.
• NC filters are recommended for protecting the lens.
• To prevent ghosting, use of a filter is not recommended when the subject is
framed against a bright light, or when a bright light source is in the frame.
• Center-weighted metering is recommended with filters with exposure factors
(filter factors) over 1 × (Y44, Y48, Y52, O56, R60, X0, X1, C-PL, ND2S, ND4, ND4S,
ND8, ND8S, ND400, A2, A12, B2, B8, B12). See the filter manual for details.
Viewfinder
eyepiece
accessories
• DK-20C Eyepiece Correction Lenses: Lenses are available with diopters of –5, –4, –3,
–2, 0, +0.5, +1, +2, and +3 m
–1
when the camera diopter adjustment control is
in the neutral position (–1 m
–1
). Use eyepiece correction lenses only if the
desired focus can not be achieved with the built in diopter adjustment control
(–1.7 to +1.0 m
–1
). Test eyepiece correction lenses before purchase to ensure
that the desired focus can be achieved.
The rubber eyecup can not be used
with eyepiece correction lenses.
• Magnifier DG-2: The DG-2 magnifies the scene displayed in the center of the
viewfinder for greater precision during focusing. Eyepiece adapter required
(available separately).
• Eyepiece Adapter DK-22: The DK-22 is used when attaching the DG-2 magnifier.
The monitor can not be rotated with the adapter in place.
• Right-Angle Viewing Attachment DR-6: The DR-6 attaches at a right angle to the
viewfinder eyepiece, allowing the image in the viewfinder to be viewed at
right angles to the lens (for example, from directly above when the camera is
horizontal). The monitor can not be rotated with the attachment in place.
Software
• Capture NX 2: A complete photo editing package offering such features as white
balance adjustment and color control points.
• Camera Control Pro 2: Control the camera remotely from a computer to record
movies and photographs and save photographs directly to the computer hard
disk.
Note: Use the latest versions of Nikon software. Most Nikon software offers an
auto update feature (Nikon Message Center 2) when the computer is connected
to the Internet. See the websites listed on page xii for the latest information on
supported operating systems.

Nikon D5300 Specifications

General

Megapixel	24.2 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Sensor format	Advanced Photo System type-C (APS-C)
Image stabilizer	No
Total megapixels	24.78 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Supported aspect ratios	3:2
Maximum image resolution	6000 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	6000 x 4000, \\r 4496 x 3000, \\r 2992 x 2000
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	39
Auto focusing (AF) modes	Continuous Auto Focus, Contrast Detection Auto Focus, Multi Point Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Auto Focus (AF) points selection	Auto, Manual
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 12800, 25600, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash sync-speed	1/200 s
Shoe mounting point type	Hot shoe
Flash exposure correction	-3EV - +1EV (1/3 EV step)
Power source type	Battery
Video resolutions	640 x 424, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3.2 \
Display resolution	720 x 480 pixels
Display resolution (numeric)	1036800 pixels
Magnification	0.82 x
Viewfinder type	Optical
USB version	2.0
HDMI connector type	Mini
Product color	Silver
Scene modes	Portrait, Landscape (scenery)
Photo effects	Black&White, Neutral, Vivid
White balance	Auto, Cloudy, Flash, Fluorescent, Incandescent, Manual, Shade, Sunny
Playback modes	Rotation, Slideshow, Zoom
Shooting modes	Aperture priority, Auto, Lens priority, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Highlights, Movie, Single image, Slide show
Image processor	EXPEED 4
Self-timer delay	2, 5, 10, 20 s
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3, RAW
Diopter adjustment (D-D)	-1.7 - 1
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Battery type	EN-EL14a
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 85 %
Cables included	USB
Bundled software	ViewNX 2
Wi-Fi standards	802.11b, 802.11g

Weight and Dimensions

Depth	76 mm
Width	125 mm
Height	98 mm
Weight	480 g
Weight (including battery)	530 g
