6
4 Operating your pressure washer
4.1 Connection of high pres-
sure hose
1. Mount the high pressure
hose on the outlet (3).
4.2 Mounting of spray
lance and Click & Clean
nozzles
,
Note: The
spray lance (6)
has a built-in low
pressure nozzle that can be
used for fl ushing away dirt.
2. Attach the nozzle.
Warning: When
attaching the Click
& Clean nozzles,
the pawl on the
side of the spray
lance should come out again.
Note: The Tor-
nado
®
PR noz-
zle and the foam
sprayer feature a swivel lock,
which must be positioned in the
hole in the Click & Clean spray
lance.
Press the pawl to detach the
Click & Clean nozzle.
3.4 Mounting of high pres-
sure hose
Attach the high pressure hose
(4) to the spray gun (7).
Detach the high pressure hose
by pressing the pawl (A).
1. Push the spray lance (6) into
the spray gun (7) and screw
it on.
