Nokia Lumia 930 RM-1045 User Manual

Service Manual Level 1 and 2
Nokia Lumia 930
RM-1045
Version 1.0
Product controls and interfaces
2
7
1
3
4
6
5
9
12
10
11
15
19
8
20
14
13
17
18
16
9 — Back key
8 — Home key
7 — Touch screen
6 — 2nd Microphone
5 — Ambient light & Proximity sensor
4 — Front camera
3 — Earpiece
2 — 3.5mm Headset connector
1 — Nano-SIM holder
10 — Search key
11 — Main microphone
12 — Micro-USB connector
13 — 3rd Microphone
14 — LED Flash
15 — Camera
16 — Volume keys
17 — Power/Lock key
18 — Camera key
19 — Loudspeaker
20 — 4th Microphone
21 — GPS/BT/WLAN Antenna area
22 — MIMO Antenna area
23 — NFC Area
24 — Wireless charging area
25 — Main Antenna area
25
21
23
24
22
