Nokia N79 Service Manual

N79 RM-348 / RM-349 / RM-350
Service Manual Level 1&2
ISSUE 1
Confidential
12
10. DISASSEMBLY INSTRUCTION
1) Nokia N79 disassembly. 2) You must use the Nokia Standard Tool kit version 2,
SS-148 and SS-100.
3) To remove the C-COVER, push the button on the
bottom side…
4) … and remove the C-COVER.
5) Insert the SS-148 and rotate it clockwise… 6) … so that the edges of the A-COVER are unlocked. Do
not fully rotate the SS-148 as this would damage the B-
COVER.
Copyright @ 2008 NOKIA. All rights reserved

Nokia N79 Specifications

General

Display diagonal	2.4 \
Display resolution	320 x 240 pixels
Display number of colors	16.78 million colors
Ringer type	Polyphonic
Internal memory	50 MB
Sensor type	CMOS
Rear camera type	Single camera
Rear camera resolution	2584 x 1938 pixels
Video capture resolution (max)	640 x 480 pixels
Headphone connectivity	3.5 mm
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Talk time (2G)	5.5 h
Battery capacity	1200 mAh
Standby time (2G)	372 h
Personal info management (PIM)	Alarm clock, Calculator, Calendar, To-do list
Form factor	Bar
Product color	-
2G standards	EDGE, GPRS
Data network	3G, wcdma
Bluetooth version	2.0+EDR

Weight and Dimensions

Depth	15 mm
Width	49 mm
Height	110 mm
Weight	97 g
