6
1. With the help of a second person, carefully raise the
Uprights (70) until the Wheels (30) are resting flat on the
floor.
Assembly
Assembly requires two people. Set the treadmill in a cleared area and remove all packing materials. Assembly
requires a phillips screwdriver (not included).
1
70
30
2. Remove the two indicated Screws (43) from the left Upright
(70).
Attach the Storage Latch (5) and the two Latch Spacers
(93) to the left Upright (70) with the two Screws (43). Be
careful not to overtighten the Screws.
Note: If it is difficult to fold or lower the treadmill,
remove one or both of the Latch Spacers (93).
2
70
93
43
5
4. Make sure that all parts of the treadmill are properly
tightened. Place a mat beneath the treadmill to
protect the floor or carpet.
3. Remove the backing from the Wrench Clip (88). Press the
Wrench Clip onto the left or right Upright (70) in the indi-
cated location. Press the Allen Wrench (87) into the
Wrench Clip.
3
70
88
89
To Next Page
