Nordson 3100 User Manual

Overview
A 2-12
E 2000 Nordson Corporation
All rights reserved
41-3000
Issued 11/00
A2EN-02-[3-OVER]–2
Manifold Description
A Non-circulating, 4-port, piston pump, SF
B Non-circulating, 6-port, piston pump, SF
C Non-circulating, 6-port, piston pump, RFF
F Internal circulating, 4-port, DC gear pump, SF, CV
J Internal circulating, 4-port, AC/DC gear pump, SF, PCV
K Internal circulating, 6-port, DC gear pump, SF, PCV
L Internal circulating, 6-port, DC gear pump, RFF, PCV
O Internal circulating, 6-port, DC gear pump, SF, CV
P Internal circulating, 6-port, DC gear pump, RFF, CV
S External circulating, 2-port, piston pump, SF, CV
T External circulating, 2-port, piston pump, RFF, CV
U External circulating, 2-port, DC gear pump, RFF, PCV
R External circulating, 2-port, DC gear pump, SF, PCV
SF = standard filter
RFF = reverse-flush filter
PCV = pressure control valve
CV = circulation control valve
Control Description
1 UniScan
3 MultiScan
Electrical
Capacity
Description
2 2 hoses/2 guns
4 4 hoses/4 guns
6 6 hoses/6 guns
Options Description
A Low-level switch
C Temperature setback (MultiScan only)
D Digital temperature display, temperature band monitoring,
and temperature setback (MultiScan only)
E I/O board, piston pump melters (MultiScan only)
F I/O board, gear pump melters (MultiScan only)
K English/Japanese language tags
P Pressure dump (motor and pressure control only)
Q Motor and pressure control (MultiScan only)
R CE certification
T Key-to-line control (MultiScan only)
U Electric line filter
Understanding the Melter
Configuration Code
(contd.)
