Nulite PB60Y/32 User Manual

2.3 Exploded view
NL-PB25Y-35Y-50Y-60Y-70Y/32
Lett panel
Air outlet grill
Front panel
Right panel
Terminal block cover
Controller cover
Top cover
Chassis components
Centre wall
Compressor
Titanium heat exchanger
Low pressure switch
High pressure switch
Filter
Electronic expansion valve
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Four-way valve, pipcline assembly
Reactor
Check valve
Clip
Terminal block
Frame assembly
Electric control box cover
Electric control box
Electric control components
Sponge strip
Finned coil heat exchanger
Motor bracket
DC fan motor
A xial fan blade
16
17
18
19
20
21
22
23
24
25
26
27
28
29
NameNumber
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
NameNumber
07
