21
SPECIFICATIONS
INPUTS:
LINE: 10KΩ input impedance
110mV RMS sensitivity for 1.22V output
MIC: 600Ω input impedance (balanced)
1.2mV RMS sensitivity for 1.22V output
80mV RMS, max input
PHONO: 47KΩ input impedance
1.55mV RMS sensitivity @ 1kHz for 1.22 output
OUTPUTS:
LINE: 9.0V RMS max
HEADPHONE: 0.5W into 47Ω
DISTORTION: < 0.2%
SIGNAL-TO-NOISE RATIO
(max output, JIS-A weighted):
LINE: > 96dB
MIC: > 90dB
PHONO: > 81dB
FREQUENCY RESPONSE:
LINE: 20Hz – 20kHz (±1.0dB)
MIC: 20Hz – 15kHz (±2.0dB)
PHONO: 20Hz – 20kHz (±1.0dB except for controlled attenuation of -3.0dB @ 20Hz to
reduce rumble and feedback)
CHANNEL EQUALIZER:
BASS: ±12dB @ 40Hz
MIDDLE: ±12dB @ 1.35kHz
TREBLE: ±12dB @ 15kHz
CHANNEL KILL: -70dB @ 20Hz – 20kHz
POWER CONSUMPTION: 26.2W (typical)
30.6W (with full headphone output)
DIMENSIONS (W x D x H): 254mm x 355mm 108mm
WEIGHT: 5.2kg
