PLATTER SETUP
WARNING: Incorrect Platter setup can lead to poor turntable performance, platter instability, or
permanent motor damage.
1. Start by inspecting the bottom of the aluminum platter to check that both locking pins have rubber
fittings on them.
2. Next, rotate the top of the motor assembly (brass in color) so that two holes are aligned parallel with
the front of the turntable.
3. Install the platter onto the center spindle and motor assembly making sure that the Numark logo and
the two holes are aligned parallel with the front of the turntable.
4. The two locking pins should drop into the top of the motor assembly for a stable and secure fit. If they
do not, grasp the center spindle with one hand while rotating the platter with the other until the
locking pins drop into place. If the platter is properly installed, it should not wobble and should rotate
smoothly without any noise.
1. 2.
Locking Pins
ALIGNED
3. 4.
PAGE 3 PLATTER SETUP
