92 – C330/C530 Replacing Consumables and Maintenance
Replacing the Transfer Belt Unit ____
The belt unit is located under the image drum assembly.
Switch off the printer and allow the fuser to cool for about
10 minutes before opening the cover.
1. Press the cover release and open the printer’s top cover fully.
WARNING!
If the printer has been powered on, the fuser will be
hot. This area is clearly labelled. Do not touch.
