INSTRUCTIONS
Thank you for purchasing this Olympus product.
To ensure your safety, please read this
instruction manual before use, and keep it
handy for future reference.
Name of parts (Figure 1)
1 Target brightness adjustment dial
2 Sight horizontal positioning dial
3 Pop-up switch
4 Sight vertical positioning dial
5 Target indicator
Inserting the Battery
Insert a pen or other object into part (
) and
open the battery compartment cover (Figure 2).
Insert the battery in the orientation shown and
close the cover (Figure 3). The supplied battery
is for test purposes only.
Use
Mount the product on the camera hot shoe
(Figure 4). Press the pop-up switch to ready
the sight and rotate the target brightness
adjustment dial to adjust brightness. Rotating
the dial to OFF turns the product off, as does
returning the sight to the closed position. Use
the sight positioning dials to position the target
while viewing the subject in the camera monitor.
Precautions for Use
• Do not use excessive force.
• When replacing the battery, be careful that
water does not enter the battery compartment.
• Some lenses and cameras may interfere
with operation when the device is attached.
In addition, some lenses and hoods may
obstruct the target.
Main Specifications
Target indicator : Red
Power source : One (1) CR2032 lithium battery
Weight : 72.2 g (2.5 oz.)
(including battery)
Dimensions :
Approx. 46.2 (W) × 39.3 (H) ×
77.1 (D) mm (1.8 × 1.5 × 3.0 in.)
* Specifications are subject to change without any
notice or obligation on the part of the manufacturer.
EN
