SIMPLE STEPS FOR TAKING PICTURES
Setting the Aperture
1. Open the Dust Barrier and set
the aperture lever ( mark) to the
F-number required.
2. Confirm the shutter speed in
the viewfinder, aiming at the sub-
ject.
(The arrows indicate parallax cor-
rection marks.)
If the shutter speed nee-
dle enters the striped, over-
exposure warning zone,
push the aperture lever
downward so that the nee-
dle points to "500" (1/
500 sec) or under.
If the needle points to
"30" (1/30 sec) or under,
be careful not to shake the
camera.
(To make full use of aperture con-
trol, see pages 13 & 14.)
Aperture guideline (ASA 100)
7

Olympus XA Specifications

General

Type	35mm Rangefinder Camera
Aperture Range	f/2.8 - f/22
Exposure Metering	CdS Cell
Dimensions	102 x 64.5 x 40 mm
Lens	Zuiko 35mm f/2.8
Shutter Speed	10 sec - 1/500 sec
Focus	Manual Focus
Exposure Control	Aperture priority automatic, manual
Film Speed	ISO 25 - 800
Shutter	Electronic Leaf Shutter
Battery	Two LR44/SR44 or equivalent
Weight	225 g
