Omron CJ2H-CPU6*-EIP Series Connection Guide

7
．
Serial Communications Connection Procedure
13
10
Connect 24 VDC power supply
to 24 VDC power supply input
terminal (CN5).
11
Connect 100 VAC power supply
to Main power supply input
terminal (TB1).
*For details on the handling of
power supply wiring and
protective earth terminal, refer
to Brushless Motor and Driver
Package BLE Series FLEX
RS-485 communication type
USER MANUAL (HM-5140).
24 VDC power supply
input terminal (CN5)
24 VDC
power supply
GND
24V
Main power supply
input terminal (TB1)
100 VAC
power supply
