Omron E5CC-QX2ASM-800 User Manual

E5CC-800/E5CC-B-800/E5CC-U-800
3
Optional Products (Order Separately)
Terminal Covers (for E5CC-800)
Note: The E53-COV10 cannot be used.
Refer to page 14 for the mounted dimensions.
Waterproof Packing
Note: This Waterproof Packing is provided only with E5CC-800/
E5CC-B-800 Controllers.
The E5CC-U-800 cannot be waterproofed even if the
Waterproof Packing is attached.
Current Transformers (CTs)
* Lead wires are included with these CTs. If UL certification is
required, use these CTs.
Adapter
Note: Use this Adapter when the panel has already been prepared for
an E5B@ Controller.
DIN Track Mounting Adapter (for E5CC-800)
Sockets (for E5CC-U-800)
Waterproof Cover
Mounting Adapter
Note: This Mounting Adapter is provided with the Digital Temperature
Controller.
Front Covers
Model
E53-COV17
E53-COV23 (3pcs)
Model
Y92S-P8
Hole diameter Model
5.8 mm E54-CT1
5.8 mm E54-CT1L *
12.0 mm E54-CT3
12.0 mm E54-CT3L *
Model
Y92F-45
Model
Y92F-52
Type Model
Front-connecting Socket P2CF-11
Front-connecting Socket with Finger Protection P2CF-11-E
Back-connecting Socket P3GA-11
Terminal Cover for Back-connecting socket
with Finger Protection
Y92A-48G
Model
Y92A-48N
Model
Y92F-49
Type Model
Hard Front Cover Y92A-48H
Soft Front Cover Y92A-48D
