Omron E5CC-RX2ASM-802 User Manual

E5EC-800/E5EC-B-800/E5AC-800
24
Heating and Cooling Control
●Using Heating and Cooling Control
A Control Output Assignment
If there is no control output 2, an auxiliary output is used as the cooling control output.
If there is a control output 2, the two control outputs are used for heating and cooling.
(It does not matter which output is used for heating and which output is used for cooling.)
B Control
If PID control is used, you can set PID control separately for heating and cooling.
This allows you to handle control systems with different heating and cooling response characteristics.
Optional Products (Order Separately)
Terminal Covers (for E5EC-800/E5AC-800)
Waterproof Packing
Note: This Waterproof Packing is provided with the Digital
Temperature Controller.
Waterproof Cover
Front Port Cover
Note: This Front Port Cover is provided with the Digital Temperature
Controller.
Mounting Adapter
Note: This Mounting Adapter is provided with the Digital Temperature
Controller.
Current Transformers (CTs)
* Lead wires are included with these CTs. If UL certification is
required, use these CTs.
Model
E53-COV24 (3pcs)
Applicable Controller Model
E5EC-800/
E5EC-B-800
Y92S-P9
E5AC-800 Y92S-P10
Applicable Controller Model
E5EC-800/
E5EC-B-800
Y92A-49N
E5AC-800 Y92A-96N
Model
Y92S-P7
Model
Y92F-51
(Two Adapters are included.)
Hole diameter Model
5.8 mm E54-CT1
5.8 mm E54-CT1L
*
12.0 mm E54-CT3
12.0 mm E54-CT3L
*
