6
UNIT DISPLAY
Diastolic Blood Pressure
Systolic Blood Pressure
Memory Symbol
Pulse Display
Date/Time Display
Battery Low Symbol
Average Value Symbol
Heartbeat Symbol
Deflation Symbol
IRREGULAR HEARTBEAT SYMBOL
When the monitor detects an irregular rhythm two or more times during
the measurement, the Irregular Heartbeat Symbol ( )
will appear on the display with the measurement values.
The irregular heartbeat rhythm is defined
as a rhythm that varies by more than or less
than 25% from the average rhythm detected
while the monitor is measuring the
systolic and diastolic blood pressure.
If the irregular heartbeat symbol ( )
displays with your measurement results we
recommend you consult your physician.
Follow the directions of your doctor.
Normal Heartbeat
Irregular Heartbeat
Pulse
Blood
pressure
Pulse
Blood
pressure
Short Long
Irregular Heartbeat Symbol
IRREGULAR HEARTBEAT SYMBOL
Movement Error Symbol
HEM-711-IM-US-6097 6/7/05 11:34 AM Page 6
