Setting Ranges
●K8AK-TH11S
Centigrade
Fahrenheit
●K8AK-TH12S
Centigrade
Fahrenheit
●Temperature Input Range
Input K J T E Pt100 Pt1000
Setting tempera-
ture range
1,000
800
600
400
200
0
999 850 400 600 850 850
000000
Minimum setting increment
1°C
Input K J T E Pt100 Pt1000
Setting temperature
range
1,000
800
600
400
200
0
999 999 700 999 999 999
Å@ Å@ Å@ Å@ Å@
000000
Minimum setting increment
1°F
Input KJTEBRSPLII
Setting temperature
range
1,800
1,700
1,600
1,500
1,400
1,300
1,200
1,100
1,000
900
800
700
600
500
400
300
200
100
0
1,800
1,700 1,700
1,300 1,300
850
600
400
100
0000 000
Minimum setting increment
10°C
Input KJTEBRSPLII
Setting temperature
range
3,200
3,100
3,000
2,900
2,800
2,700
2,600
2,500
2,400
2,300
2,200
2,100
2,000
1,900
1,800
1,700
1,600
1,500
1,400
1,300
1,200
1,100
1,000
900
800
700
600
500
400
300
200
100
0
3,200
3,000 3,000
2,300 2,300
1,500
1,100
700
300
0000 000
Minimum setting increment
10°F
TH11S °C °F TH12S °C °F
Input
type
Lower
limit
Upper
limit
Lower
limit
Upper
limit
Input
type
Lower
limit
Upper
limit
Lower
limit
Upper
limit
K −20 1019 −40 1039 K −20 1320 −40 2340
J −20 870 −40 1039 J −20 870 −40 1540
T −20 420 −40 740 T −20 420 −40 740
E −20 620 −40 1039 E −20 620 −40 1140
Pt100 −20 870 −40 1039 B 0182003240
Pt1000 −20 870 −40 1039 R −20 1720 −40 3040
--- --- --- --- --- S −20 1720 −40 3040
--- --- --- --- --- PLII −20 1320 −40 2340
