15
Connecting with Bi-Amping Speakers (Page 12)
Make sure you remove the jumper bar fitted between the
woofer jacks and tweeter jacks of the front speakers. Refer
to "Standard Connections (Pages 8 to 11)" (P14) to connect
the center speaker, surround speakers, and powered
subwoofer.
0 Also refer to the instruction manual for your speakers
when using connections for Bi-Amping.
Make sure the exposed wires of the speakers
do not stick out of the speaker terminals when
connecting. If the exposed wires of the
speakers touch the rear panel or the + and –
wires touch each other, the protection circuit
will be activated.
> Before Start > Part Names >Install > Initial Setup > Playback > Advanced Manual
Troubleshooting | Supplementary Information, etc.
For high-
frequency
For low-
frequency
Setup
0 Settings for the speaker configuration you have
connected need to be made in "1. AccuEQ Room
Calibration" in Initial Setup (P24).
0 If any of the connected speakers have an
impedance of 4 Ω or more to less than 6 Ω, after
completing Initial Setup, you need to make some
settings in the Setup menu. Press on the
remote controller, select "2. Speaker" -
"Configuration" and set "Speaker Impedance" to
"4ohms".
To Next Page
