Onkyo A-9010 Service Manual

2/2 PAGE
A-9010(B)WDC
PC BOARD PARTS LIST
: NSP
CIRCUIT NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
C157 CAP, ELECT (47uF/50V, 8X11.5_FG) (for audio) 1 CCEA1HFG470T
C257 CAP, ELECT (47uF/50V, 8X11.5_FG) (for audio) 1 CCEA1HFG470T
C302 CAP, ELECT (47uF/50V, 8X11.5_FG) (for audio) 1 CCEA1HFG470T
C304 CAP, ELECT(25V/220uF,ELNA/RA3) (for audio) 1 CCEA1ERA38P221T
C307 CAP, ELECT (330uF/50V, 10X16, RA3) (for audio) 1 CCEA1HRA38P331E
C308 CAP, ELECT (330uF/50V, 10X16, RA3) (for audio) 1 CCEA1HRA38P331E
C402 CAP, ELECT (47uF/50V, 8X11.5_FG) (for audio) 1 CCEA1HFG470T
C404 CAP, ELECT(25V/220uF,ELNA/RA3) (for audio) 1 CCEA1ERA38P221T
C407 CAP, ELECT (330uF/50V, 10X16, RA3) (for audio) 1 CCEA1HRA38P331E
C408 CAP, ELECT (330uF/50V, 10X16, RA3) (for audio) 1 CCEA1HRA38P331E
C905 CAP, ELECT(8200uF/50V, 105'C, 30X4 1 CCET50VHE822NH
C906 CAP, ELECT(8200uF/50V, 105'C, 30X4 1 CCET50VHE822NH
D1202 L.E.D , GREEN (5mm Pitch Taping) 1 CVDGY34MU22Y16BJTAA4
D1204 L.E.D , GREEN (5mm Pitch Taping) 1 CVDGY34MU22Y16BJTAA4
D1206 L.E.D , GREEN (5mm Pitch Taping) 1 CVDGY34MU22Y16BJTAA4
D1208 L.E.D , GREEN (5mm Pitch Taping) 1 CVDGY34MU22Y16BJTAA4
D1210 L.E.D , GREEN (5mm Pitch Taping) 1 CVDGY34MU22Y16BJTAA4
D1212 L.E.D , GREEN (5mm Pitch Taping) 1 CVDGY34MU22Y16BJTAA4
D1214 L.E.D , AMBER (5mm Pitch Taping) 1 CVDGY34MU2202JTAAL
D1222 L.E.D , AMBER (5mm Pitch Taping) 1 CVDGY34MU2202JTAAL
D1224 L.E.D , AMBER (5mm Pitch Taping) 1 CVDGY34MU2202JTAAL
IC04 I.C , AUDIO SELECTOR(8-IN 4-OUT,SS NJW1112V 1 22242597R2
IC05 I.C , 2CH VOLUME NJW1194V 1 22242893R2
JK05 4P SCREW SPK (RR/BB,GOLD,94V-0,Tra 1 CJJ5P035Z
JK221 MODULE , OPTICAL(RX 16MHz) 1 CJSJSR1124
Q309 T.R , PRE DRIVE KTA1360-Y 1 2204250
Q310 T.R , PRE DRIVE KTC3423-Y 1 2204240
Q409 T.R , PRE DRIVE KTA1360-Y 1 2204250
Q410 T.R , PRE DRIVE KTC3423-Y 1 2204240
RY191 RELAY,HL31-1AT-5H,DC5V,1C1P 1 CSL1C006ZE !
RC118 SENSOR , REMOTE/U 1 CRVKSM603TH5B
SW134 ENCODER 1 CSR2A037Z
T1905 TRANS , SUB C515 1 CLT5I009ZU !
VR131 RES, VARIABLE(STRAIGHT) B 50K 1 CVV3V03B503Z
VR132 RES, VARIABLE(STRAIGHT) B 50K 1 CVV3V03B503Z
VR133 RES, VARIABLE(STRAIGHT) B 50K 1 CVV3V03B503Z
VR141 VOLUME, MOTOR (B CURVE, 50Kohm) 1 CVV9Y17B503Z
JK136 JACK , HEADPHONE (SILVER) 1 CJJ2D003Z
JK197 JACK, STEREO (BLK MOLD) 1 CJJ2D008Z
JK151 JACK, PHONES(6.35mm,SILVER) 1 CJJ2E026Z
JK211 JACK , RCA (1P,RCA-115A-04) 1 CJJ4M044X
JK01 JACK, 2P(W /R),SEPA-GND, SILVER 1 CJJ4N034U
JK02 JACK, 4P(W /R,W/R),SEPA-GND 1 CJJ4P048U
JK03 JACK, 4P(W /R,W/R),SEPA-GND 1 CJJ4P048U
JK04 JACK, 2P(W /R),SEPA-GND, SILVER 1 CJJ4N034U

Onkyo A-9010 Specifications

General

Damping factor	95
Amplifier class	-
Frequency range	10 - 100000 Hz
Input sensitivity	150 mV
Audio output channels	2.0 channels
Peak power per channel	44 W
Signal-to-Noise Ratio (SNR)	92 dB
Total Harmonic Distortion (THD)	0.08 %
Purpose	Home
Product color	Black
Connectivity technology	Wired
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.4 W
Power consumption (typical)	25 W
Package weight	8200 g
Manual	Yes

Weight and Dimensions

Depth	3 mm
Width	435 mm
Height	129.5 mm
Weight	6500 g
