A-955
5
<Note>
Parts marked by "NSP" are generally unavailable because
they are not in our Master Spare Parts List.
<Notes>
(B) : Black model
(S) : Silver model
(G) : Golden model
<DC> : Canadian model
<PP> : European model
<GT> : Asian model
<DT> : Taiwanese model
<GR> : Chinese model
[U] : Made in Japan
[M] : Made in Malaysia
EXPLODED VIEW PARTS LIS
T
REF. NO. NAME DESCRIPTION Q'TY PART NO. REMARKS
EV
A001 F BRACKET --- 1 27111426
EV
A002 SCREW 3TTB+8B(CU)SR 23 8016118
EV
A005 SCREW 3P+10FN(3BC) 2 82143010GR
EV
A008 RETAINER (SEL) 1 27141998
EV
A009 RETAINER (HP) 1 27141999
EV
A021 CHASSIS --- 1 --- NSP
EV
A022 LEG AS 4 27175425
EV
A025 CUSHION --- 4 28141647
EV
A026 SCREW 3TTB+8B(3BC) 4 838430088GR
EV
A029 BRACKET (PT) 1 27130994A
EV
A030 SCREW 3TTB+8B(3BC) 4 838430088GR
EV
A033 HOLDER KGLS-16RT 11 27190511
EV
A034 SCREW 3TTB+8B(CU)SR 5 801618
EV
A035 CLAMP WS-2NS 2 27300833
EV
A036 HOLDER (CRAMP) UA-0 V0 3 27190608-1
EV
A037 TAPE TAPE(CLOTH-16U) (1) 29110083
EV
A043 HEAT SINK (S)221 2 27160578A
EV
A045 PC BUSH(3) --- 4 800529
EV
A046 SCREW 3TTB+8B(CU)SR 5 801618
EV
A048 SCREW 3TTB+8B(CU)SR 6 801618
EV
A051 GUIDE (POW) 1 27268163
EV
A052 KNOB (SEL-BASE) 1 28326414A (B)
EV
A052 KNOB (SEL-BASE) 1 28326413A (S)
EV
A052 KNOB (SEL-BASE) 1 28326415A (G)
EV
A053 KNOB (SEL-BASE2) 1 28326417 (B)
EV
A053 KNOB (SEL-BASE2) 1 28326416 (S)
EV
A053 KNOB (SEL-BASE2) 1 28326418 (G)
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
