Onkyo DV CP704 Service Manual

DV-CP704
SPECIFICATION
Specifications and features subject to change without notice.
Signal system
Standard NTSC (U.S. model), PAL/AUTO (Australian
model)
Frequency
response
DVD linear audio
4 Hz - 22 kHz @ 48 kHz sampling rate
4 Hz - 44 kHz @ 96 kHz sampling rate
CD audio 4 Hz - 20 kHz (44.1 kHz)
Signal-to-noise ratio 95 dB
Audio dynamic range 95 dB
Total harmonic distortion 0.007% (1 kHz)
Wow and Flutter Below threshold of measurability
Operating
conditions
Temperature 5 C to 35 C (41 F to 95 F)
Installation Install horizontally
Video outputs
COMPONENT VIDEO
Y: 1.0 V (p-p), 75 ohm, negative sync, RCA/phono x 3
P
B/PR: 0.7 V (p-p), 75 ohm
S VIDEO (S-Video)
Y: 0.7 V (p-p), 75 ohm, negative sync, 4-pin mini DIN x 1
C: 0.286 V (p-p), 75 ohm
VIDEO (composite video) 1.0 V (p-p), 75 ohm, negative sync, RCA/phono x 1
Audio outputs
OPTICAL -22.5 dBm, optical connector x 1
COAXIAL 0.5 V (p-p), 75 ohm, RCA/phono x 1
ANALOG 2.0 V (rms), 540 ohm, RCA/phono x 2
HDMI output 19 pin connector
General
Power supply
120 V AC, 60 Hz (U.S. model)
100 - 240 V AC, 50/60 Hz (Australian model)
Power consumption 13 W
Power consumption in Standby mode
0.35 W (U.S. model)
0.35 W (Australian model)
Weight 5.5 kg (12.1 lbs.)
Dimensions (W x H x D) 435 X 91 X 432 mm (17-1/8 X 3-9/16 X 17 ins.)
Disc compatibility
Audio CD, DVD-Video, MP3, WMA, JPEG, CD-R/RW,
DVD-R/RW (Video Mode), DVD+R/RW (Video Mode).
Discs that have not been property finalized may only be
partially playable or not playable at all.

Onkyo DV CP704 Specifications

Operating Environment

Operating temperature	5° to 35° C (41° F to 95° F)

Power

Power supply (U.S. model)	120 V AC, 60 Hz
Power supply (Australian model)	100–240 V AC, 50/60 Hz
Power consumption	13 W
Power consumption in Standby mode (U.S. model)	0.35 W
Power consumption in Standby mode (Australian model)	0.35 W

Audio Specifications

Signal-to-noise ratio	95 dB
Audio dynamic range	95 dB
Total harmonic distortion	0.007% (1 kHz)
Wow and flutter	Below threshold of measurability

Video Outputs

Component video Y	1.0 V (p–p), 75 Ω, negative sync, RCA/phono x3
Component video PB/PR	0.7 V (p–p), 75 Ω
S VIDEO Y	0.7 V (p–p), 75 Ω, negative sync, 4-pin mini DIN x1
S VIDEO C	0.286 V (p–p), 75 Ω
Composite video	1.0 V (p–p), 75 Ω, negative sync, RCA/phono x1

Audio Outputs

Optical output	–22.5 dBm, optical connector x1
Coaxial output	0.5 V (p–p), 75 Ω, RCA/phono x1
Analog output	2.0 V (rms), 540 Ω, RCA/phono x2
HDMI output	19 pin connector

Weight and Dimensions

Weight	5.5 kg (12.1 lbs.)
Dimensions (W x H x D)	435 X 91 X 432 mm (17-1/8 X 3-9/16 X 17 ins.)
