Onkyo DV CP704 User Manual

52
SN 29344218
I0607-1
Sales & Product Planning Div. : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN
Tel: 072-831-8023 Fax: 072-831-8124
ONKYO U.S.A. CORPORATION
18 Park Way, Upper Saddle River, N.J. 07458, U.S.A.
Tel: 201-785-2600 Fax: 201-785-2650 http://www.us.onkyo.com/
ONKYO EUROPE ELECTRONICS GmbH
Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY
Tel: +49-8142-4401-0 Fax: +49-8142-4401-555 http://www.eu.onkyo.com/
ONKYO EUROPE UK Office
Suite 1, Gregories Court, Gregories Road, Beaconsfield, Buckinghamshire, HP9 1HQ
UNITED KINGDOM Tel: +44-(0)1494-681515 Fax: +44(0)-1494-680452
ONKYO CHINA LIMITED
Unit 1&12, 9/F, Ever Gain PlazaTower 1, 88, Container Port Road, Kwai Chung,
N.T., HONG KONG Tel: 852-2429-3118 Fax: 852-2428-9039
http://www.ch.onkyo.com/
(C) Copyright 2006 ONKYO CORPORATION Japan. All rights reserved.
http://www.onkyo.com/
HOMEPAGE
* 2 9 3 4 4 2 1 8 *
Specifications
Specifications and features subject to change without notice.
Signal system
Standard NTSC (U.S. model), PAL/AUTO (Australian
model)
Frequency
response
DVD linear audio
4 Hz–22 kHz @ 48 kHz sampling rate
4 Hz–44 kHz @ 96 kHz sampling rate
CD audio 4 Hz–20 kHz (44.1 kHz)
Signal-to-noise ratio 95 dB
Audio dynamic range 95 dB
Total harmonic distortion 0.007% (1 kHz)
Wow and flutter Below threshold of measurability
Operating
conditions
Temperature 5° to 35° C (41° F to 95° F)
Installation Install horizontally
Video outputs
COMPONENT VIDEO
Y: 1.0 V (p–p), 75 Ω, negative sync, RCA/phono x3
PB/PR: 0.7 V (p–p), 75 Ω
S VIDEO (S-Video)
Y: 0.7 V (p–p), 75 Ω, negative sync, 4-pin mini DIN x1
C: 0.286 V (p–p), 75 Ω
VIDEO (composite video) 1.0 V (p–p), 75 Ω, negative sync, RCA/phono x1
Audio outputs
OPTICAL –22.5 dBm, optical connector x1
COAXIAL 0.5 V (p–p), 75 Ω, RCA/phono x1
ANALOG 2.0 V (rms), 540 Ω, RCA/phono x2
HDMI output 19 pin connector
General
Power supply
120 V AC, 60 Hz (U.S. model)
100–240 V AC, 50/60 Hz (Australian model)
Power consumption 13 W
Power consumption in Standby mode
0.35 W (U.S. model)
0.35 W (Australian model)
Weight 5.5 kg (12.1 lbs.)
Dimensions (W x H x D) 435 X 91 X 432 mm (17-1/8 X 3-9/16 X 17 ins.)
Disc compatibility
Audio CD, DVD-Video, MP3, WMA, JPEG, CD-R/RW,
DVD-R/RW (Video Mode), DVD+R/RW (Video Mode).
Discs that have not been property finalized may only be
partially playable or not playable at all.

Onkyo DV CP704 Specifications

Operating Environment

Operating temperature	5° to 35° C (41° F to 95° F)

Power

Power supply (U.S. model)	120 V AC, 60 Hz
Power supply (Australian model)	100–240 V AC, 50/60 Hz
Power consumption	13 W
Power consumption in Standby mode (U.S. model)	0.35 W
Power consumption in Standby mode (Australian model)	0.35 W

Audio Specifications

Signal-to-noise ratio	95 dB
Audio dynamic range	95 dB
Total harmonic distortion	0.007% (1 kHz)
Wow and flutter	Below threshold of measurability

Video Outputs

Component video Y	1.0 V (p–p), 75 Ω, negative sync, RCA/phono x3
Component video PB/PR	0.7 V (p–p), 75 Ω
S VIDEO Y	0.7 V (p–p), 75 Ω, negative sync, 4-pin mini DIN x1
S VIDEO C	0.286 V (p–p), 75 Ω
Composite video	1.0 V (p–p), 75 Ω, negative sync, RCA/phono x1

Audio Outputs

Optical output	–22.5 dBm, optical connector x1
Coaxial output	0.5 V (p–p), 75 Ω, RCA/phono x1
Analog output	2.0 V (rms), 540 Ω, RCA/phono x2
HDMI output	19 pin connector

Weight and Dimensions

Weight	5.5 kg (12.1 lbs.)
Dimensions (W x H x D)	435 X 91 X 432 mm (17-1/8 X 3-9/16 X 17 ins.)
