DV-SP502/502E
DVD MAIN BOARD PARTS LIST-1
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
NOTES:
560 ohm
47k ohm
0.5 ohm
1 ohm
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
5.62k ohm RN1/4PC F562 x 10
1
5621
Mark No. Description Part No.
A
LOAB ASSY
SWITCHES AND RELAYS
S101 VSK1011
OTHERS
CN602 KR CONNECTOR S2B-PH-K
CN601 KR CONNECTOR S5B-PH-K
PC BOARD LOAB VNP1879
B
DVD MAIN BD ASSY
SEMICONDUCTORS
IC321 BA00BC0WT
IC502,IC602,IC702 BA4560F
IC204 BR24L16FV-W
IC202 K4S641632H-TC75
IC101 M63018FP
IC401 MM1623BF
IC201 MT1389EE-L1
IC801 NJM78M05FA
IC501,IC601,IC701 PCM1742KE
IC311 PQ1M505M2SPQ
IC205 PST3228
IC341 S-L2980A33MC-C6S
IC841 TC7SHU04FU
IC203 VYW2202
Q562,Q662,Q762 2SA1576A
Q372,Q373 2SA1602A
Q371,Q4,Q901 2SC4081
Q541,Q542,Q544,Q545 2SD2114K
Q641,Q642,Q741,Q742 2SD2114K
Q7,Q8 HN1A01F
Q592,Q593 HN1C01FU
Q5 UM5K1N
Q561,Q661,Q761 UMH9N
D801 1SS355
D591 UDZS6.8B
COILS AND FILTERS
L421,L422 CHIP BEAD VTL1089
L311 CHIP BEAD VTL1095
CAPACITORS
C292,C293,C297 CCSRCH101J50
C265 CCSRCH220J50
C142,C227 CCSRCH221J50
C294,C295,C903 CCSRCH330J50
